Teres 300 mounted reversible plough

Rotating each pair of plough bodies enables you to change the furrow width quickly and simply. You can choose between 35, 40, 45, and 50 cm for each body. The soil-engaging tools and disc coulters are also adjusted automatically.

• Setting the furrow width by turning the plough bodies

The furrow width of the Teres V and Teres VS ploughs can be adjusted steplessly via the hydraulics on the tractor. A clearly visible display, consisting of a scale and pointer, keeps the driver informed of the furrow width setting. Via the integrated kinematics, the Teres also sets the front furrow width, all the soil engaging tools and the support wheel automatically.

The advantages of the Teres V and VS

• Variable furrow width from 30 cm to 55 cm per body
• Automatic adjustment of the front furrow when changing the furrow width thanks to AutoAdapt
• No readjustment necessary
• Comfortable and time-saving operation

After lifting the plough, the beam is swivelled in without causing any stress before the turnover process starts. The furrow width is not changed by swivelling in the beam. This prevents wear, especially on the plough body bearings, and also enables a higher ground clearance during turnover. Once the plough has been turned, the frame swivel cylinder automatically returns the beam to the working position. The swivel cylinder extends in accordance with the furrow width. In this respect, a push/pull cable relays the position of the furrow width to a valve, thereby restricting the cylinder travel.

Practical use of the frame swivel cylinder
