The intelligent agitator
» Intelligent agitator

The agitator stars are positioned over the low-lying outlet opening and ensure continuous fertiliser flow. When the shutter slides are closed on both sides, the agitator speed is reduced to protect the fertiliser.

Electrically-adjustable Limiter V+
» Limiter V+

The sensitive electrical adjustment of the Limiter V+ border spreading device to the respective field boundary enables convenient switching between field-side, border and water course spreading from the tractor cab during fertiliser application.

1) The fertiliser flow is only diverted to the long spreading vanes with a low working height of the Limiter V+.
2) If the Limiter V+ is lowered further, the fertiliser flow is diverted to both spreading vanes.
3) The fins provide a precise spread pattern up to the border in the completely lowered position.

  1. Weighing frame
  2. Horizontally aligned tie rods
  3. Weigh cells
» Profis weighing technology

Precise monitoring and control of the application rate using the 200 Hz weighing technology and the tilt sensor. No calibration. Just enter the spread rate and drive away with perfect monitoring of the tank level at all times.

1) Horizontally aligned tie bars
2) Weighing frames
3) Weighing cells

» mySpreader-App:

The first all-in-one package containing the FertiliserService App, EasyCheck App and EasyMix App for blended fertiliser for perfect spreader adjustment. More...

» GPS-Switch

GPS-Switchpoints

The automatic part-width section control, having up to 16 part-width sections, guarantees precise switching on wedge shaped fields and at the headland. Outer part-width sections can also be controlled – this increases precision and makes it easier for the driver. More...

We need your consent

This content is provided by an external server. By activating the content, personal data may be accessed and Cookies may be utilised.

AMAZONE Precision TODAY: ZA-V mounted spreaders

We need your consent

This content is provided by an external server. By activating the content, personal data may be accessed and Cookies may be utilised.

SmartLearning - EasyCheck

Precise spreading made easy – a digital, mobile test kit for the easy optimisation of the lateral distribution. Instead of using the test trays, as with the normal mobile test kit, the EasyCheck system consists of just 16 lightweight rubber mats and the EasyCheck App for smartphones.

We need your consent

This content is provided by an external server. By activating the content, personal data may be accessed and Cookies may be utilised.

ZA-V mounted spreaders

The ZA-V mounted spreader is available in hopper capacities from 1,400 to 4,200 l and is characterised by its high working speeds of up to 30 km/h. Exceptionally high work rates are achieved thanks to its high spreading capacity of up to 390 kg/min and working widths of up to 36 m.

ZA-V mounted spreaders

You can find more product pictures here.
