PRECISION is in the air
World champions in combinations
Maximum operator comfort – Maximum precision
AMAZONE offers the perfect seed drill combination for any farm “from a single source”. Today we present our Centaya Super and AD-P Special pneumatic precision seed drills. You can choose from rotary harrows, rotary cultivators or the CombiDisc mounted compact disc harrow. You can configure your new seed drill with either the TwinTeC double disc sowing coulter or RoTeC single disc sowing coulter, because, with AMAZONE, the choice is yours!
See for yourself!
The AMAZONE Team
AD-P Special
The reliable precision seed drill
- Hopper capacity 850 l or 1,250 l and 1,500 l with a hopper extension
- Working width 3 m, 3.5 m and 4 m
- RoTeC single disc sowing coulter or WS suffolk coulters
- Central, compact seed hopper with a hopper capacity from 850 l to 1,500 l
- Dust-proof roll-over cover
- Simple and convenient operation via the AmaDrill+ in-cab terminal or an ISOBUS-compatible operator terminal
- High comfort and short set-up times thanks to excellent access to the electrically-driven metering unit
- Flexible use thanks to easily interchangeable metering cassettes for different seed types
- The electric metering drive provides precise metering and easy calibration via the TwinTerminal or from the tractor cab
- Considerable reduction in the use of seed in wedge-shaped fields, thanks to electric half-side shut-off
- Soil tillage with a rotary harrow or rotary cultivator with working speeds up to 12 km/h
- Wide range of rollers – the right roller for every soil
- Easy separation of the seed drill for solo use of the soil tillage tool
- RoTeC single disc sowing coulter for even seed placement, even in very wet conditions
- Optional: GPS-Switch with AutoPoint for optimum switching points on the headland
- Optional: comfortable hydraulic coulter pressure adjustment from the tractor cab with easy-to-read display
Comfort-Pack 1 with TwinTerminal 3.0
Comfort-Pack 1 with TwinTerminal 3.0 is available for the AD-P Special and the Centaya Super, in order to make pre-metering, calibration and residue emptying even easier. This enables pre-metering, calibration and emptying of any hopper residues directly down at the machine.
Electric metering drive
The electric metering drive is controlled by the AmaDrill+ in-cab terminal (Super AmaDrill 2 in the Centaya), the AmaTron 4 ISOBUS terminal or any other ISOBUS terminal. In conjunction with the electric drive, calibration is comfortable and fully automated. The electric drive also offers additional functions such as the pre-metering of the seed in field corners and the increase and decrease of the seed rate during operation.
Metering cassettes for different seed types
- 7.5 ccm (e.g. for linseed, poppies)
- 20 ccm (e.g. for rape, stubble turnips, lucerne)
- 120 ccm (e.g. for green manure, maize, sunflowers)
- 210 ccm (e.g. for barley, rye, wheat)
- 600 ccm (e.g. for spelt, oats, wheat, peas)
Centaya Super
The most comfortable precision seed drill
- Hopper capacity 1,600 l or 2,000 l
- Working width 3 m, 3.5 m and 4 m
- RoTeC pro single disc coulter or TwinTeC double disc coulter
- Large, central seed hopper with an advantageous centre of gravity very close to the tractor and a hopper capacity of 1,600 l or 2,000 l for high work rates
- Dust-proof roll-over cover
- Simple and convenient operation via the AmaDrill 2 in-cab terminal or an ISOBUS-compatible operator terminal
- High comfort and short set-up times thanks to excellent access to the electrically-driven metering unit
- Flexible use thanks to easily interchangeable metering cassettes for different seed types
- The electric metering drive provides precise metering and easy calibration via the TwinTerminal or from the tractor cab
- Considerable reduction in the use of seed in wedge-shaped fields, thanks to electric half-side shut-off
- Soil tillage with a rotary harrow or rotary cultivator with working speeds up to 12 km/h or up to 15 km/h in combination with the CombiDisc compact disc harrow
- Wide range of rollers – the right roller for every soil
- QuickLink quick coupling system for quick connection of the seed drill
- Comfortable hydraulic coulter pressure adjustment from the tractor cab with easy-to-read display
- As an option:
– TwinTeC double disc sowing coulter with centralised coulter pressure adjustment and integrated press roller for direct reconsolidation of the seed
– RoTeC pro single disc sowing coulter for even seed placement, even in very wet conditions
SmartCenter adjustment centre
With the new SmartCenter for the Centaya, AMAZONE offers an extremely clear and simple layout of the most important settings.
– Central adjustment of the placement depth of the TwinTeC sowing coulters
– Comfortable calibration at the push of a button or via the TwinTerminal
AmaDrill 2 in-cab terminal
All the requisite work settings can be seen at a glance on the 4.7” display of the AmaDrill 2 in-cab terminal.
GreenDrill
The GreenDrill universal catch crop seeder box is the ideal solution for applying undersown crops in a single pass.
Universal operating tool
You can change a setting in no time at all. It is possible to set the following: Adjustment of the track markers, pre-emergence markers, Exact harrow, side plates and height adjustment of the levelling board and the opening of the protection sieve.
The choice is yours!
RoTeC single disc coulter …
RoTeC sowing coulter for the AD-P Special harrow-mounted seed drill …
- Tool-free adjustment of sowing depth in 3 steps.
- Reinforced support arm with a coulter pressure of up to 35 kg. Central coulter pressure adjustment.
- The Control 25 mm or 10 mm depth control and cleaning roller for an even depth control.
- Furrow former for a clean profile seed furrow.
- Seed guide tube up to the furrow former for even seed placement.
- Sowing disc ∅ 320 mm made of boron steel, working angle of 7°, for smooth operation of the coulter. 12.5 cm or 15 cm row spacing.
- Exact harrow for excellent seed coverage.
… or RoTeC pro coulter for the Centaya harrow-mounted seed drill
RoTeC pro sowing coulter (∅ 400 mm) with Control 25 depth guidance roller. The cleats, which are open at the rear, provide a very good self-cleaning effect. Suitable for high speeds yet combined with smooth operation.
- Control 25 depth guidance roller
- Furrow former
- Sowing disc
RoTeC pro sowing coulter (∅ 400 mm) with Control 10 depth guidance disc can be operated with a coulter pressure of up to 55 kg. Excellent cutting effect on heavy ground.
- With precise depth adjustment in 4 stages
- With Control 10 depth guidance disc
... or TwinTeC double disc coulter
TwinTeC sowing coulter for the Centaya harrow-mounted seed drill
- Perfect parallelogram with the top link for central adjustment of the sowing depth from 0 to 6 cm.
- Centralised, 100% independent adjustment of the placement depth and coulter pressure.
- TwinTeC sowing coulter mounted on sprung rubber buffer blocks for shock absorption and central adaptation of the coulter pressure from 0 to 60 kg.
- Protective plastic front plate.
- Spacer shims for adjustment to compensate for disc wear.
- Disc fastening in 5 locations with recessed Torx screws. No wear on the fixing discs.
- Maintenance-free bearings. No lubrication points on maintenance-free coulter.
- Double disc ∅ 340 mm, angle of 10°, row spacing 12.5 or 15 cm.
- HD internal scrapers
- Depth control rollers/press rollers: 50 or 65 mm wide (optional scrapers).
- Adjustable harrow: the angle of attack is adjusted according to the level of straw residues present.
TwinTeC – made for speed
- Parallel sharp discs in a V-arrangement with even wear.
- Opening angle of 10° to move a minimum amount of soil and ensure optimum soil flow through the machine.
- Row spacings of 12.5 cm and 15 cm.
- Angle of 10°
TwinTeC with precise depth control
A parallel-guided depth guidance roller behind each double disc sowing coulter ensures a precise placement depth, so that the placement depth of each individual TwinTeC sowing coulter is maintained. The Control 50 mm depth guidance roller has a large passage and is suited especially for heavy soils that have a good carrying ability. On the other hand, the Control 65 mm depth guidance roller offers a higher carrying capacity, which is ideal for lighter locations.
- Control 50
- Control 65
QuickLink quick coupling system
Clever, simple and flexible!
Quicklink options from the world champions in combinations
Seed drills:
- Centaya Super
pneumatic seed drill or - Avant 02 pneumatic seed drill
- Cataya conventional seed drill
- Precea-A precision air seeder
Rollers:
- KWM wedge ring roller with Matrix tyre profile
or - PW tooth packer roller
- TRW trapezium roller
- KW wedge ring roller
Soil tillage implements:
Thanks to the QuickLink quick release coupling system, the seed drill can be easily and quickly linked to the various AMAZONE soil tillage implements without the need for tools. In this way, optimised sowing combinations can be put together to cope with the most diverse of soils and applications.
Please note that not every soil tillage implement can be combined with every roller or seed drill.
Exclusive
- QuickLink
For the quick coupling of soil tillage implements with Precea 3000-ACC Super or Centaya 3000 Super
NEW
- With QuickLink – precision sowing and seedbed preparation in just one pass!
Thanks to the combination of a soil tillage implement and the harrow-mounted, Precea-A precision seeder, perfect seedbed preparation and precision sowing is provided in one pass.
Optimum seedbed preparation
with rotary harrows, rotary cultivators ...
KE rotary harrow and KX and KG rotary cultivators
- 3 m up to 4 m working width
- Long-Life-Drive system – designed for extreme loads and a long service life
- Quick + Safe-System – the proven quick change tine system and integrated stone release
... or with the CombiDisc compact disc harrow
- 3 m working width
- Easy to pull, for working speeds up to 15 km/h
- 410 mm discs – serrated
The right roller for any location
With various models of roller available, it is possible to specify a complete unit of soil tillage and drill that are perfectly matched to the prevailing soil conditions.
PW tooth packer roller/500 mm ∅/600 mm ∅
- Excellent self-driving effect
- Reconsolidation of the surface across the entire area
TRW trapezium roller/500 mm ∅/600 mm ∅
- Good carrying capability
- Strip-wise reconsolidation
KW wedge ring roller/520 mm ∅/580 mm ∅
- Universal for all soils and conditions
- Strip-wise reconsolidation
KWM wedge ring roller with Matrix tyre profile/600 mm ∅
- Produces more fine soil for the seedbed
- For improved self-driving effect
AmaTron 4 – ISOBUS terminal
Manager 4 all
Simple and convenient operation, as intuitive as your tablet
The AmaTron 4 ISOBUS terminal with its 8" Multitouch colour display meets the highest standards. No matter whether via the cleverly designed operator elements (touch/12 backlit keys/3 one-touch keys) or via the intuitive operation in day or night mode, AmaTron 4 offers maximum user-friendliness. A swipe of the finger or use of the App carousel allows quick changes between applications and the simple and clearly structured operating menu. A practical MiniView, a freely configurable status bar and an integrated light bar make the AmaTron 4 exceptionally easy and convenient to use. The AmaTron 4 ISOBUS terminal is universally usable for all ISOBUS machines from AMAZONE and other manufacturers.
Universally usable with software licences for the AmaTron 4 ISOBUS terminal:
- GPS-Switch basic: Automatic half-side shut-off for ISOBUS seed drills or automatic part-width section control with up to 16 part-width sections on ISOBUS fertiliser spreaders or ISOBUS crop protection sprayers, creation of a virtual headland, automatic boom lowering on AMAZONE crop protection sprayers
- GPS-Switch pro: Automatic part-width section control with up to 128 part-width sections for plant protection and fertilisation, marking of obstructions, e.g. water hole, pylons
- GPS-Maps&Doc: Documentation and the processing of application maps is easy and precise
- GPS-Track: visual parallel guidance aid for easier driving
- GPS-Switch basic: automatic switching on and off at the headland or automatic half-side shut-off on one side or both sides. You obtain a significant reduction in seed usage preventing over- and under-sowing, especially in wedge shaped fields and on the headland.
- AutoPoint – for optimum switching points on the headland (only AD-P Special)
- Simulation of a virtual headland
- Virtual headland
- Field application maps for different seed rates are also possible
- Worked area
- With half-side shut-off
Your options with our AD-P Special and Centaya Super pneumatic seed drills
Extremely comfortable ISOBUS machine operation. An optimal combination for improved precision during sowing in conjunction with AmaTron 4.
GPS-Maps&Doc with the integrated Task Controller:
- Automatic documentation of job-related data
- Optimisation of the seed rate by means of application maps, in order to improve yield potential
- Multi-Bin function for independent control of the application rates of several materials via different application maps
GPS-Track with ISOBUS tramline control (Level 1):
- Automatic switching of the tramline for easier driving
Avant 02 sowing combination
Maximum flexibility for conventional and mulch sowing
The Avant 02 mounted seed drill combination with an FTender front tank is the ideal machine for contractors and larger farms where both efficient conventional and mulch sowing are practised in the field. The weight distribution of the front tank with seed at the front and the rotary cultivator with a seed rail at the rear ensures optimum axle load distribution.
- Working widths of 3 m and 4 m, rigid and 6 m, folding
- FTender 1600 and 2200 front tanks with 1,600 l or 2,200 l capacity and integrated front tyre packer (optional)
- Optimum ballasting of the rear axle and front axle of the tractor
- High manoeuvrability on the field with working widths of up to 6 m
