The concept

Mastering the current challenges in seeding with the D9 from AMAZONE

Whether large or small, many farms are facing challenges such as climate change, rising costs of consumables such as seed, fertiliser and fuel, as well as the flexibility now demanded for catch crop sowing.

With the right seed drill, it is much easier to master these challenges reliably in order to produce good, high-quality food: the AMAZONE D9 mounted seed drill offers optimised sowing, especially for small and medium-sized farms.

The seed is metered mechanically from the hopper and reliably placed at the correct depth by the coulter system - every time, and under any conditions. The seedbed can, as an option, be preprepared via an up-front rotary harrow or rotary cultivator, including reconsolidation with a following roller in the same pass. High quality and AMAZONE precision, yet at a good price.

AMAZONE has been researching and developing seeding systems for 75 years. The D9 mounted conventional seed drill is the reliable seed drill that has also been developed to handle future tasks. Simple, light, modern - for successful sowing with the D9 mounted conventional seed drill under all conditions - now also with the C-Drill for simultaneous fertiliser application.

Yesterday, today and tomorrow. Always.

More information + Less information -

The D9 concept

Reliability and flexibility combined for all conditions

1. Seed hopper with a capacity of up to 1,380 litres, with the mechanically-driven Vario-gearbox for reliable seed metering
2. Tool-free coupling of KE, KG, or KX soil tillage machines, including various different rollers using the "Liftpack" system
3. Access steps and loading board for safe filling of the seed hopper
4. Universal RoTeC single disc coulter with the Control depth control and cleaning disc for both sowing after the plough or mulch sowing or with WS Suffolk coulters for conventional sowing
5. Exact harrow or drag tine harrow for neat covering over of the seed furrow
